Models four different viscoelastic compartments with one or two chambers for modeling lungs.
These equations model various configurations of a viscoelestic lung compartment as developed by Bates. Each model includes a resistance term (represented by lung resistance) and a spring recoil term (spring resistance represented by 1 / lung compliance). Each configuration of either one (simple or Maxwell) or two (parallel or series) compartment can be modified to add to a larger model or can be used alone as a simple model. While these models were developed for positive pressure ventilation, they can also be adapted for passive exhalation. If possitive pressure ventilation is used, the difference in compartment behavior is much clearer than for the passive exhalation.
Images adapted from Bates
Simple One Compartment Model
Maxwell One Compartment Model
Parallel Two Compartment Model
Series Two Compartment Model
The equations for this model may be viewed by running the JSim model applet and clicking on the Source tab at the bottom left of JSim's Run Time graphical user interface. The equations are written in JSim's Mathematical Modeling Language (MML). See the Introduction to MML and the MML Reference Manual. Additional documentation for MML can be found by using the search option at the Physiome home page.
